Light Indoor Full Color LED Display Screen Signal Backup And Power
Backup
Indoor Full Color LED Display Screen Features
1, Seamless connection.
2, Special design for the mask to realize higher contrast and
larger viewing angle.
3, Signal backup and power backup.
4, Brightness and chromaticity calibration.
Indoor Full Color LED Display Screen Details
1. Modular design for quick installation and removal
2. Highly reliable data hot backup, avoiding any communication
risks during the exhibition
3. High refresh rate up to 4200Hz, and live video without flashing
at all
4. Super brightness and color uniformity, pixel calibration before
leaving the factory
Indoor Full Color LED Display Screen Specification (parameter):
| SHENZHEN JINGCAIYUAN TECHNOLOGY CO., LTD |
|
| P2 SMD 3 IN 1 TECHNICAL parameter |
|
| Unit Module | Item | Parameter |
| Model Number | P2-32S |
| Module size | 256mm*128mm |
| Pixel pitch | 2mm |
| Pixels Density | 250000 dots/m2 |
| Pixel configuration | 1R1G1B |
| Package mode | SMD 3IN1 -1515 |
| Pixel resolution | 128dots(W)*64 dots(H) |
| Max Power | 23W |
| Module thickness | 13mm |
| Weight | 0.352KG |
| Drive type | Constant drive |
| Scan mode | 1/32scan |
| Port type | HUB75E |
| Brightness of white balance | ≥800cd/㎡ |
| LED Cabinet | Dimension | 512mm*512mm |
| Monomer Module Number | 16pcs |
| Power supply | 5V/40A*1 pcs |
| Pixel per cabinet | 256*256 |
| Best viewing distance | 2M～10M |
| Best viewing angle | 140°(W) 120°(H) |
| Temperature | storage:-35℃～+85℃ |
| working:-20℃～+50℃ |
| Relative humidity | 10%-95% |
| Thickness | 65mm |
| Power | Working voltage | AC220V±10% |
| Average Power consumption | <280W/㎡ |
| Max.Power consumption | <700W/㎡ |
| Current | <15mA(single LED) |
| Control system | CPU | Pentium4 or above |
| Operation system | WIN98/2000/NT/XP/WIN7/WIN10 |
| Control method | Synchronization |
| Main technical parameter | Driving device | Constant drive IC |
| Refresh frequency | >1920HZ |
| Grey scale/colors | 65536, can display 16.7M color |
| 65536gray level/16.7M colors |
| MTBF | >9000hours |
| Power switch | Automatic switch |
| Display Mode | ≥1024*768 |
Competitive advantages:
- Installation service, usually we are not responsible for overseas
installation, but we can provide technical support for you. If you
need this, we can arrange our technicians to your country, but the
cost is paid by the customer.
- Free lifetime maintenance and software upgrades.
- Free technical training about how to use and process software.
